Features
• High Resolution 32-bit Programmable PWM Digital Circuit
• PWM or TTL Protocol Capability <- Manual Link
• Magnetic Encoder Position Sensor
• Wide Operating Voltage (4.8 ~ 7.4V)
• Heavy-Duty, Long Life Motors
• IP65 Rated Cases
• 25 Tooth Output Shaft
• RS-485*, PWM or TTL Control Options Available
*The available RS-485 protocol option MUST be requested at the time of special order customization.
• Customization and Modification Options Available
• Custom Connector Options Available
Parts and Accessories
• Replacement Gear Set
• Replacement Case Set
• Applicable Horns and Mounting Hardware
Programmable Functions
• End Point Adjustments
• Direction
• Fail Safe
• Dead Band
• Speed (Slower)
• Soft Start Rate
• Overload Protection
• Data Save / Load
• Program Reset
