HSR-2645CR
HSR-2645CR
HSR-2645CR Click to enlarge

HSR-2645CR

Continuous Rotation Digital Robot Servo

PWM Cored Carbon Brush
12
KGF·CM
Max Torque
0.14
SEC/60°
Speed
53
GRAMS
Weight
Torque8 ~ 12 kgf·cm
Speed0.22 ~ 0.14 sec/60°
Operating Voltage4.8 ~ 7.4 V
Dimensions (L×W×H)40.6 × 19.8 × 37.8 mm
Motor TypeCored Carbon Brush
Gear TypeMetal
ProtocolsPWM
Loading 3D model…
Drag to rotate · Scroll to zoom
Product Description
Expanding on the durable and responsive power of the HSR-1425CR continuous rotation servo, we have developed the digital HSR-2645CR. This non-proportional, continuous rotation servo delivers the commanding force you require, with intense, powerful torque, wide voltage capability and Hitec’s impressive metal gear train. Responsive high speed motion and quick directional shifts make this the go-to servo for your most complex and specialized applications. Its programmability and "all-in" solid build will have radio control, robotic and engineering enthusiasts cheering. Continuous performance by Hitec! Features • Digital Circuit with Directional Programmability • Linear Speed Control • Quick Directional Shift • Low Dead Band for Precise Control • Wide Input Voltage Range
Downloads
HSR-2645CR_3dmodl
ZIP Datasheet
HSR-2645CR_Specsheet(v2.1)_22K
PDF Datasheet
