Hitec's strongest servo period, the "Monster Torque" HS-7980TH is designed to operate on a two cell LiPo Pack. Featuring our newest high resolution "G2.5" 12 bit generation programmable digital circuit and our indestructible Titanium gears, The HS-7980TH has the performance and durability you've come to expect from a Hitec servo. Other features in the HS-7980TH include a 7.4V optimized coreless motor, integrated heat sink case, and a top case with two hardened steel gear pins supported by axial brass bushing.
Applications for the HS-7980TH include high performance Giant Scale Aircraft, Truggies and Buggies, Fast Power boats, the largest aircraft, monster trucks or anywhere else you can use 600+ inch ounces of torque.
The upgraded version of this servo is now available : D980TW
Features
• G2.5 12 bit Digital Programmable Circuit
• Titanium Gear Train (MK first gear)
• Ultra Performance Coreless Motor
• Integrated Heatsink Case
• (8) O-Rings for Water/Dust/Fuel protection
• Dual Ball Bearing Supported Output Shaft
• 10% larger than a HS-7955TG
Programmable Functions
• End Point Adjustments
• Direction
• Fail Safe
• Dead Band
• Speed (Slower)
• Overload Protection
• Resolution
• Data Save / Load
• Program Reset
