HS-5065MG

High Torque Metal Gear Feather Servo

PWM Cored Metal Brush
2.2
KGF·CM
Max Torque
0.11
SEC/60°
Speed
11.9
GRAMS
Weight
Torque1.8 ~ 2.2 kgf·cm
Speed0.14 ~ 0.11 sec/60°
Operating Voltage4.8 ~ 6 V
Dimensions (L×W×H)23.6 × 11.6 × 2.4 mm
Motor TypeCored Metal Brush
Gear TypeMetal
ProtocolsPWM
Loading 3D model…
Drag to rotate · Scroll to zoom
Product Description
PlasticHitec raised the bar by offering the ever popular HS-65 in a new digital version! The HS-5065MG High Performance Micro Servo features Hitec's digital, programmable circuit for incredible resolution, centering and holding torque; also featuring metal gears, a top-ball bearing, and at 31 oz./in. of torque with a quick transit time of 0.11 sec at 6 volts, it is no doubt THE choice for high performance micro helicopters, electric park flyers, and 1/18 scale cars. Features • Top Selling Digital Feather Servo • Ball Bearing-Supported Output Shaft • Standard Programmable Digital Circuit for More Holding Power • High Torque and High Speed • Accurate Centering Programmable Functions • End Point Adjustments • Direction • Fail Safe • Dead Band • Speed (Slower) • Data Save / Load • Program Reset
Downloads
hs-5065mg_3dmodl
ZIP Datasheet
HS-5065MG_Specsheet(v2.1)_22K
PDF Datasheet
