Model	SPEED RANGE (SEC/60°)		TORQUE RANGE (KG•CM)		DIMENSION (MM)			WEIGHT(G)	Protocol (Possibility)
Model	MIN	MAX	MIN	MAX	L	W	H	WEIGHT(G)	PWM	TTL	RS485	CAN	DRONE CAN
MDB961WP-DroneCAN-28V	0.14	0.14	60	60	40	20	39	90					DRONE CAN
MDB961WP-CAN-28V	0.14	0.14	60	60	40	20	39	90				CAN
MDB961WP-DroneCAN	0.18	0.15	55	55	40	20	39	90					DRONE CAN
MDB961WP-CAN	0.18	0.15	55	55	40	20	39	90				CAN
MDB941WP-DroneCAN	0.085	0.07	20.6	25.4	40	20	39	91.7					DRONE CAN
MDB941WP-CAN	0.085	0.07	20.6	25.4	40	20	39	91.7				CAN
DB961WP	0.18	0.15	55	55	40	20	39	90	PWM	TTL
DB951WP	0.12	0.1	38	38	40	20	39	90	PWM	TTL
SG50BL-CAN-24V-CIRCULAR-CONN	0.5	0.5	520	520	100	50	105	1450				CAN	DRONE CAN
SG33BLT-CAN-24V-GLAND-CABLE	0.185	0.185	147	147	64	33	90	500				CAN	DRONE CAN
SG33BLT-CAN-24V-CIRCULAR-CONN	0.185	0.185	147	147	64	33	90	480				CAN	DRONE CAN
SG33BLT-24V-DB9SUB-CONN	0.185	0.185	147	147	64	33	95	480	PWM	TTL	RS485
SG33BLT-CAN-12V-GLAND-CABLE	0.185	0.185	147	147	64	33	90	500				CAN	DRONE CAN
SG33BLT-CAN-12V-CIRCULAR-CONN	0.185	0.185	147	147	64	33	90	480				CAN	DRONE CAN
SG33BLT-12V-DB9SUB-CONN	0.185	0.185	147	147	64	33	95	480	PWM	TTL	RS485
SG20BL-CAN-12V-CIRCULAR-CONN	0.13	0.13	65	65	45	20	75	170				CAN	DRONE CAN
SG15BL-CAN-12V-CIRCULAR-CONN	0.123	0.123	11	11	31	15	50	40				CAN	DRONE CAN
MDB1200WP	0.22	0.18	100	110	62	30	47	260	PWM	TTL
MD845WP	0.26	0.17	32.5	50	66	32	62	227	PWM	TTL
HS-1100WP	0.26	0.19	84	110	64	33	73	363	PWM
D845WP	0.26	0.17	32.5	50	66	32	62	227	PWM	TTL
D840WP	0.17	0.11	19	30	66	32	62	227	PWM	TTL
D956WP	0.19	0.12	16	24.5	40	20	37	72.4	PWM	TTL
D646WP	0.24	0.16	7.5	11.6	41.8	21	40	61	PWM	TTL
DB778WP	0.12	0.1	18	18	41	21	26.5	66	PWM	TTL
DB777WP	0.08	0.06	8	11	41	21	26.5	68	PWM	TTL
HS-5646WP	0.2	0.18	11.3	12.9	41.8	21	40	61	PWM
HS-5086WP	0.18	0.15	3	3.6	31	15.2	31	28.5	PWM
HS-646WP	0.2	0.17	9.6	11.6	41.8	21	40	60	PWM
